NUCLEUS UXP AV Gateways
UXP-TRXS-UCPT - Standalone Transceiver Gateway w/ USB Capture
The UXP-TRXS-UCPT standalone AV gateway is a single device that can either be used as a receiver, a transmitter, or both at the same time. In additon to its AV transport capabilites, the UXP-TRXS-UCPT has been designed to facilitate integration of complex AV media flows with Unified Collaboration applications. Operating system and application agnostic, the new gateways require no drivers and are plug-and-play with Microsoft Windows, MAC, and Linux workstations. Providing an uncompressed, no latency USB 3 Type-C output, the gateways appear as an audio-enabled webcam to your favorite conferencing application enabling the use of high quality HDMI or SDI PTZ cameras and Pro AV multiview authoring solutions for Broadcast-quality compositions in an Enterprise setting.
UXP-TRS4K-2A - Standalone AV Gateway w/ Dante™ Audio
The UXP-TRS4K-2A standalone AV gateway accepts up to two HDMI inputs or provides up to two HDMI outputs (software defined and dependent on network bandwidth) and, along with audio and USB HID, transports them with ultra low latency over its transport links. In addition to its HDMI, analog, and S/PDIF audio capabilities, the UXP-TRS4K-2A supports Dante audio, facilitating up to 32x32 simultaneous Dante audio streams. This allows for local HDMI embedded or remote IP-ingested audio streams to be routed as Dante audio or vice versa (i.e. Dante audio streams to be routed to the local HDMI output port or transported via IP to remote destinations).
UXP-TRS4K-12G - Standalone 4K/60 12G-SDI Gateway
The UXP-TRS4K-12G is a versatile 12G-SDI gateway that supports resolutions of up to 3840px2160p @ 59.94 Hz and has three main modes of operation: dual transmit mode, dual receive mode, and single transceive mode. The UXP-TRS4K-12G is a standalone device, which is compact and quiet and can be installed in various in-room locations, including behind monitors, under/inside desks and lecterns, and floor boxes.
UXP-RXS-WP - Single-Channel HDMI AV Receiver Wall Plate
The UXP-RXS-WP AV receiver is a no-nonsense, cost-effective, single-channel HDMI video and audio wall plate receiver. The UXP-RXS-WP has one HDMI output port supporting resolutions of up to 3840x2160p @ 30 Hz and receives AV content with ultra low latency over its transport link. Additional functionality includes support for 802.3at Type 2 PoE+ and RS-232 for serial communication and control. Pair the UXP-RXS-WP with EvertzAV's UXP-TXS-WP single-channel HDMI AV transmitter wall plate for an unbeatable low-cost AV transport solution.
UXP-TXS-WP - Single-Channel HDMI AV Transmitter Wall Plate
The UXP-TXS-WP AV transmitter is a no-nonsense, cost-effective, single-channel HDMI video and audio wall plate transmitter. The UXP-TXS-WP has one HDMI input port supporting resolutions of up to 3840x2160p @ 30 Hz and transmits AV content with ultra low latency over its transport link. Additional functionality includes support for 802.3at Type 2 PoE+ as well as RS-232 for serial communication and control. Pair the UXP-TXS-WP with EvertzAV's UXP-RXS-WP single-channel HDMI AV receiver wall plate for an unbeatable low-cost AV transport solution.
UXP-TRXS-5G - Standalone 5G HEVC/H.264 Encoder / Decoder
The UXP-TRXS-5G is a standalone 5G-enabled HEVC/H.264 encoder / decoder that features one HDMI input and one HDMI output with the option of installing a 12G SDI SFP+ transceiver to allow for the transport of SDI video and embedded audio. The UXP-TRXS-5G can simultaneously encode and decode video signals with a maximum resolution of up to 4K60 (10-bit, 4:2:2). The UXP-TRXS-5G is a compact and fanless standalone device utilizing 5G wireless technology – an ideal gateway for applications such as live streaming, mobile broadcasting, mobile surveillance, and remote operation.
UXP-TRXS-HC - Standalone HEVC/H.264 Encoder / Decoder
The UXP-TRXS-HC is a standalone HEVC/H.264 encoder / decoder that features one HDMI input and one HDMI output with the option of installing a 12G SDI SFP+ transceiver to allow for the transport of SDI video and embedded audio. The UXP-TRXS-HC can simultaneously encode and decode video signals with a maximum resolution of up to 4K60 (10-bit, 4:2:2). The UXP-TRXS-HC is a compact and fanless standalone device with robust encode/decode capabilities – an ideal gateway for various applications such as live streaming, surveillance, broadcasting, and more.
UXP-TRS4K-4x2 - Standalone AV Dual HDMI Transceiver
The UXP-TRS4K-4x2 standalone AV dual HDMI transceiver accepts up to four HDMI inputs and provides up to two HDMI outputs, in addition to audio and USB. The UXP-TRS4K-4x2 is a standalone device which is compact and quiet and can be installed in various in-room locations, including behind monitors, under/inside desks and lecterns, and floor boxes. The UXP-TRS4K-4x2U version of the product offers USB 2.0 (Host or Device), which can be sent at full bandwidth over the network.
UXP-HUBA-32x32 - Network-Enabled 32x32 Analog Audio Switch with Dante™
The UXP-HUBA-32x32 is a versatile professional audio switch designed to support seamless internal switching from any of its inputs to any of its outputs. With 32 mono channel (16 balanced stereo) line level analog audio inputs and outputs, Dante™ audio interoperability, and support for 32 ST302M stereo pairs on both of its SFP+ ports, the UXP-HUBA-32x32 is an audio switching powerhouse.
UXP-RS4K-4 - Standalone 10GE AV Quad Image Processor / Receiver
The UXP-RS4K-4's quad display functionality allows you to select up to four video sources, individually scale and arrange the layout of the video sources, and then output to a 4K60 raster (with optional alpha blending on the video source windows if desired). This quad display functionality is applicable to each HDMI output independently. Video sources can be chosen using either four network transport sources or via the four local HDMI 2.0a 4K inputs (up to 4096x2160p @ 60 Hz, 4:4:4 color sampling). 16 predefined preset display layouts are available to choose from or you can customize your own layout using manual mode.
UXP-TRXS-USB2 - Standalone AV Gateway w/ USB 2.0
The UXP-TRXS-USB2 standalone AV gateway is a device that can either be used as a receiver, a transmitter, or both at the same time. Due to the bi-directional nature of the links the UXP-TRXS-USB2 can be used to both send and receive video (with the video source/sink being either HDMI or SDI), audio, serial, USB HID, and USB 2.0 data. Reduce decision making at design time by simply adding up the number of devices that need to either send or receive as the UXP-TRXS-USB2 can be used for any connection point.
UXP-TXS - Standalone Single-Channel HDMI AV Transmitter
The UXP-TXS AV transmitter is a no-nonsense, cost-effective, single-channel HDMI video and audio transmit gateway. It is a compact and quiet standalone device with an integrated fan that can be mounted/installed in various in room locations, including behind monitors, and under desks, lecterns, and floor boxes. Reduce decision making at design time by simply adding up and ordering the number of transmitting end points you need in your system.
UXP-TXS-2 - Standalone Dual-Channel HDMI AV Transmitter
EvertzAV's UXP-TXS-2 AV transmitter is a no-nonsense, cost-effective, dual-channel HDMI video and audio transmit gateway supporting 1G and 2.5G transport rates. The UXP-TXS-2 has been designed to take advantage of the fact that more and more entry-level COTS switches support 2.5G, and thus it employs intelligent auto sensing technology that automatically adjusts video quality based on the available transport rate. Moreover, the UXP-TXS-2 is a compact and quiet standalone device with an integrated fan that can be mounted/installed in various in room locations, including behind monitors, and under desks, lecterns, and floor boxes. Reduce decision making at design time by simply adding up and ordering the number of transmitting end points you need in your system.
UXP-TXS-2-USB2-P - Standalone Dual-Channel HDMI AV Transmitter w/ USB 2.0
EvertzAV's UXP-TXS-2-USB2-P standalone AV transmitter is a feature-rich, dual-channel HDMI video and audio transmit gateway supporting 1G and 2.5G transport rates. The UXP-TXS-2-USB2-P has been designed to take advantage of the fact that more and more entry-level COTS switches support 2.5G, and thus it employs intelligent auto sensing technology that automatically adjusts video quality based on the available transport rate. The UXP-TXS-2-USB2-P can be used send video (with the video source being either HDMI or SDI), audio, serial, USB HID, and USB 2.0 data. It is a compact and quiet standalone device with an integrated fan that can be mounted / installed in various in room locations, including behind monitors, and under desks, lecterns, and floor boxes.
UXP-RXS - Standalone Single-Channel HDMI AV Receiver
The UXP-RXS AV receiver is a no-nonsense, cost-effective, single-channel HDMI video and audio receive gateway. It is a compact and quiet standalone device with an integrated fan that can be mounted/installed in various in room locations, including behind monitors, and under desks, lecterns, and floor boxes. Reduce decision making at design time by simply adding up and ordering the number of receiving end points you need in your system.
UXP-TRS4K - Standalone AV Gateway
The UXP-TRS4K standalone AV gateway accepts one HDMI input and one HDMI output. The UXP-TRS4K is a standalone device which is compact and quiet and can be installed in various in room locations, including behind monitors, and under/inside desks, lecterns, and floor boxes. In addition to one HDMI input and output the TRS4K also accepts a discrete audio input and output.
UXP-TRS4K-2 - Standalone AV Gateway
The UXP-TRS4K-2 standalone AV gateway accepts up to two HDMI inputs or provides up to two HDMI outputs (software defined and dependent on network bandwidth), in addition to audio and USB. The UXP-TRS4K-2 is a standalone device which is compact and quiet and can be installed in various in-room locations, including behind monitors, under/inside desks and lecterns, and floor boxes. In addition to two HDMI inputs or outputs, the -2U version of the product offers USB 2.0, which can be sent at full bandwidth over your 1GbE network.
UXP-TRS4K-2UH - Standalone AV Gateway w/ USB Host Port
The UXP-TRS4K-2UH standalone AV gateway accepts up to two HDMI inputs or provides up to two HDMI outputs (software defined and dependent on network bandwidth), in addition to audio and USB. The UXP-TRS4K-2UH is a standalone device which is compact and quiet and can be installed in various in-room locations, including behind monitors, under/inside desks and lecterns, and floor boxes. In addition to two HDMI inputs or outputs, the UXP-TRS4K-2UH offers a USB host port, which can be sent at full bandwidth over your 1GbE network.
UXP-TRM4K - Modular AV Gateway
The UXP-TRM4K modular AV gateway accepts a single HDMI input and HDMI output, in addition to audio and HID. The UXP-TRM4K is a modular device and is installed in an Evertz rack mount modular frame. This approach offers flexibility and density as well as a secure and reliable solution for mounting next to servers. In addition to an HDMI input and output the UXP-TRM4K can send and receive embedded audio, discrete audio, and HID USB over your IP network.
UXP-TRM4K-2 - Modular AV Gateway
The UXP-TRM4K-2 modular AV gateway accepts up to two HDMI inputs or provides up to two HDMI outputs (software defined and dependent on network bandwidth), in addition to audio and USB. The UXP-TRM4K-2 is a modular device and is installed in an Evertz rack mount modular frame. This approach offers flexibility and density as well as a secure and reliable solution for mounting next to servers. In addition to two HDMI inputs or outputs, the -2U version of the product offers USB 2.0, which can be sent at full bandwidth over your 1GbE network.
UXP-FR9 - Standard Rack Mountable 4RU Frame for Up To Nine UXP Gateways
The UXP-FR9 is a cost-effective, high-density solution developed to house up to nine of EvertzAV’s low-cost 1080p/4K30 series of UXP gateways. With its standard 4RU form factor, five fans for active cooling, and integrated cable management components, the UXP-FR9 is a extremely simple yet effective organizational hardware element of the NUCLEUS ecosystem that was designed with space saving and clutter reduction in mind.
