MMA10G-TRS4K-N
Standalone IPMX-Ready 4K/60 HDMI Gateway
Key Features
- One HDMI 2.0A input and one HDMI 2.0A output
- Resolution up to 4096x2160p @ 60Hz, 4:4:4 color sampling
- IPMX-ready with support for JPEG-XS, AES67, PTP, and more
- Ultra low latency transport over 10GE links
- Customizable EDID tables
- Full integration with MAGNUM-AV management system
- Remote monitoring capabilities using SNMP protocol
Standalone 4K Gateway
The MMA10G-TRS4K-N standalone 10GE gateway accepts one HDMI input and one HDMI output. The MMA10G-TRS4K-N is a standalone device which is compact and quiet and can be installed in various in room locations, including behind monitors, and under/inside desks, lecterAns, and floor boxes. In addition to one HDMI input and output the MMA10G-TRS4K-N also accepts a discrete audio input and output.
Live AV Transport
Using 10Gbps Ethernet the MMA10G-TRS4K-N encapsulates video, audio, HID, and Ethernet control data at the same time. The MMA10G-TRS4K-N has one HDMI 2.0A 4K (up to 4096x2160p @ 60Hz, 4:4:4 color sampling) input port and one HDMI 2.0A output port and transports them with ultra low latency over its 10GE links. Customizable EDID tables and scaling on the output paths insure the smoothest handoff between sources and sinks.
IPMX - Bringing ProAV and Broadcast Closer Together
The MMA10G-TRS4K-N is a gateway that conforms to the emerging AV-over-IP open standard IPMX and, as such, complies with the suite of standards detailed in SMPTE ST 2110 and supports features such as JPEG-XS, AES67, and PTP. EvertzAV's line of IPMX-ready gateways provide synchronized, real-time broadcast-quality AV over IP while ensuring the ProAV interoperability requirements of today and tomorrow are met.
Fully integrated with Evertz' MAGNUM-AV Controller
MMA10G-TRS4K-N is a managed element of the MMA-10G network which is controlled by MAGNUM-AV. MAGNUM-AV simplifies management and control over the system and allows for simple user control using EvertzAV's virtual control panels and touch friendly graphical user interfaces (VUE) or via third-party control systems.
Remote Monitoring
The MMA10G-TRS4K-N can be remotely monitored via the SNMP protocol using Evertz' award winning VistaLINK Pro NMS software suite. VistaLINK allows a single user from a single workstation complete visibility into the operation of the MMA-10G ecosystem. Users can prevent issues from becoming outages quickly and easily using Evertz' VistaLINK Pro.
Product Images
Specifications
| MMA10G-TRS4K-N | |
|---|---|
| Video Inputs | 1 HDMI 2.0a |
| Video Outputs | 1 HDMI 2.0a |
| Supported Resolutions | Up to 4096x2160p @ 60 Hz (4:4:4 color sampling) |
| Audio Inputs | 1 stereo balanced analog (terminal header) |
| Audio Input Impedance | High impedance |
| Audio Input Level | Line level (+4dBu) |
| Audio Outputs | 1 stereo balanced analog (terminal header) 2 S/PDIF |
| Audio Output Impedance | 600 Ω |
| Audio Output Level | Line level (+4dBu) |
| USB | 2 HID device ports (type A) 1 HID host port (micro type B) |
| Ethernet Transport | 10/100/1000 BASE -T RJ45 Ethernet Port (IEEE 802.3) |
| Ethernet Connector | RJ45 |
| 10GE Outputs | 2 SFP+ (see available accessories) |
| 10G Redundancy | Yes |
| Output Scaling | Yes |
| HDMI Audio | LPCM (up to 8 channels) Passthrough support for Dolby Digital®/AC-3, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS®, DTS-ES, DTS-HD High Res, DTS-HD Master Audio, DTS:X |
| IPMX Support | SMPTE ST 2110, JPEG-XS, AES67, PTP |
| SNMP Support | Yes |
| In-Band Control | Yes |
| Control System | MAGNUM-AV |
| Web-Based Configuration | Yes |
| Security Compliance | Compliant with applicable DoD Network Devices Security Technical Implementation Guide (STIG) findings |
| DC Input Voltage | 12VDC via supplied power adapter |
| Power Supply | 100-240V / 47-63Hz AC input; 12VDC / 5A output |
| Power Consumption | 30W |
| Operating Temperature | 32° to 104° F (0° to 40° C) |
| Relative Humidity | 10% to 90% RH (non-condensing) |
| Dimensions (H x W x D) | 1.81in x 8.25in x 6.56in (45.97mm x 209.55mm x 166.62mm) |
| Weight | 32 oz (907.19 g) |
Ordering Information
| MMA10G-TRS4K-N | Standalone IPMX-ready 4K/60 HDMI gateway: HDMI input or output, audio, HID USB, and Ethernet |
|---|
Available Accessories
| MMA10G-SFP-TR85 | SFP+, 10GE, 850nm, MMF, 50/125, LC/LC |
|---|---|
| MMA10G-SFP2-TR13 | SFP+, 10GE, 1310nm, SMF, 9/125, LC/LC, 10km |
| MMA10G-SFP-SFP-MM3 | 3m SFP+ to SFP+ fiber patch cable, 10GE, AOC, 850nm |
| 3405PS-6HO | Six output primary and redundant auto-ranging power supply, 100V - 240V AC at 50/60Hz |
